Bearing assemblies made of plastic (POM)
Type LVK

Product image Bearing assemblies made of plastic (POM) Type LVK

Description

Franke LVK type bearing assemblies are ready-to-install bearings with housing rings made of plastic (POM) and integrated bearing elements. Franke LVK are suitable for medium rotational speeds and accuracies and are available from stock. Designed as 4-point bearings, they absorb equally high loads from all directions and are insensitive to shocks and vibrations. LVK bearing assemblies are insensitive to environmental influences and can also be used in food technology and pharmacy.

Properties - Evaluation

Smooth running
Resilience
Speed
Stiffness
Weight
Price

Technical data

Material

Inner/Outer ring: Polyoxymethylene (POM)
Ball races: Non corrrosive Steel (1.4310)
Rolling elements: Non corrosive Steel
Cage: Polyamid (PA12)

Operating temperature

-10 °C to +80 °C, short-term up to +100 °C

Peripheral speed

Max. 4 m/s

Lubricant

Klüber UH1 14-151

Relubrication

Via grease nipples to DIN 3405

Technical advice


Data tables

Compare data and calculate load cases
Technical Drawing LVK
LVK Table part 1
Name KKØ
mm
Dimensions
mm
Attachment per ring
Dah8 Dd Dg DiH8 H H1 La Li
LVK-0100 100 150 6,6 6,6 50 24 20 135 65 6x
LVK-0150 150 200 6,6 6,6 100 24 20 185 115 8x
LVK-0200 200 250 6,6 6,6 150 24 20 235 165 8x
LVK Table part 2
Name KKØ
mm
Load ratings
kN
Stat. M.
kNm
Weight
kg
Order no. Availability Calculation
on request
C0a C0r Ca Cr C0m
LVK-0100 100 5,6 2,0 5,6 2,0 0,07 0,5 612952
LVK-0150 150 8,1 2,9 5,6 2,0 0,14 0,8 612302
LVK-0200 200 10,6 3,8 10,6 3,8 0,25 1,0 612304
Radial and axial runout accuracy
Diagram Radial and axial runout accuracy LVK
Rotational resistance
Diagram Rotational resistance LVK
Bearing diameter KK∅
Attachment per ring Stat. load rate C0 ax. Stat. load rate C0 rad. Dyn. load rate C ax. Dyn. load rate C rad. Stat. Moment C0m Weight Available
