Aluminum guide

An aluminium guide is a linear guide whose rail and carriage are made of aluminium. Raceways made of hardened steel are inserted into the aluminium profile, and running rollers roll on them. The raceways take up the loads, which is why the rest of the construction can be made of lightweight aluminium.

Design

An aluminium guide consists of a profile rail and a carriage that runs on it. Alternatively, two roller shoes run on two separate rails; the guide width then results from the distance between the rails. The running rollers sit in the carriage or the roller shoe and roll on the inserted raceways. Franke running rollers have a groove matched to the wire track. This patented guidance prevents the rollers from shifting on their bearing pins and rubbing against the housing. More on this in the Franke linear guide principle.

Materials

  • Rail body, carriage and roller shoes: aluminium, anodised
  • Raceways: spring steel, stainless steel for corrosion resistant types
  • Running rollers: rolling bearing steel with needle bearings or ball bearings, sealed and lifetime-lubricated

Properties

  • around half the weight of conventional steel guides, correspondingly less drive energy
  • maintenance-free over the entire service life, no relubrication
  • quiet running, only an even swish
  • any mounting position, speed up to 10 m/s, minus 20 to plus 80 degrees Celsius (type FDA)
  • profile rails in one piece from 200 to 4,000 mm, can be joined on request

Thermal expansion

Aluminium expands about twice as much as steel when heated. In aluminium machines this is an advantage: guide and construction expand equally, so no temperature related distortion occurs. In steel constructions with large temperature fluctuations, the different expansion has to be taken into account in the design.

Aluminium guides at Franke

Since 1970 Franke has transferred the principle of the wire race bearing to linear guides, and since 1992 with roller guides made of aluminium. The standard range includes the type FDA with needle bearings, corrosion resistant types with stainless steel raceways (see corrosion resistant linear guide) as well as non magnetic, lubricant free, highly dynamic and vacuum compatible versions. Individually, the Franke wire raceways can be applied to almost any aluminium profile; carriage shape, length and the number and arrangement of the running rollers can be chosen freely.

Fields of application

Aluminium guides are used in automation technology, packaging technology, medical technology and mechanical engineering, for example for machine doors, robot axes and machine elements. Wherever moving masses need to stay small, the low weight shows its strength.

Frequently asked questions about aluminium guides

What is an aluminium guide?

A linear guide whose rail and carriage are made of aluminium. Running rollers roll on raceways made of hardened steel that are inserted into the aluminium profile.

Do the rollers run directly on the aluminium?

No. At Franke, the rollers run on inserted raceways made of spring steel or stainless steel. These take up the loads; the aluminium only holds the raceways.

Does an aluminium guide need to be lubricated?

No. The needle bearings or ball bearings in the running rollers are sealed and lifetime-lubricated. For the food industry, lubricant free versions are available.

How much lighter is an aluminium guide than a steel guide?

Base bodies made of aluminium halve the weight compared with conventional steel guides.

Is an aluminium guide corrosion resistant?

Rail and carriage are anodised. For humid environments and frequent cleaning, Franke offers types with raceways and running rollers made of stainless steel.

Matching products from the Franke standard range: FDA profile rail with carriage | FDA pair of roller shoes

Franke also manufactures linear guides individually to your specifications: Individual linear guides

Linear guide: profile rail with carriage type FDA
